Support Devices: please check with us for not listed or new PIC chip Please add 1.5M USB 2.0 Cablefor extra USB cable.USB cable is not providedto save material and shipping cost.Standard 2.54mm Pin Socket for ICSP connection.iCP01v2.0 Dimension: 6.2cm X 2.5cm X 0.5cm, easy to carry and store.3.3V supply, J-Series and in-Circuit Debugging mode are not supported.Supported for 5V operation voltage only.Supported for 3.3V, J-Series PIC family with external VDD power supply.Supported for 5V VDD operation voltage (supplied by programmer).

VPP First Program Entry (VDD control) feature.

Full-Speed USB & High Voltage programming.

Excellent flexibility that allows using in both PC desktop and laptop.

Compatible with Microchip's PICkit 2, MPLAB IDE and MPLAB X.

120mA current output at 5V VDD pin with over-current protection.

Supported operating systems (32bit/64bit): Windows XP ,Windows Vista, Windows 7, Windows 8, Windows 10, Linux and Mac OS X.

Used for programming up to 200 type of popular Flash PIC MCU, includes PIC10F, PIC12F, PIC16F, PIC18F and dsPIC30 family.

Every part is assembled perfectly and programmer is tested before submitting to users.

Low cost, small size, high performance and user friendly device.

iCP01v1.0 & v2.0 Features & Specification: By the same time, it allows users to program their hex code into the well-known Flash PIC MCU by using commonplace USB connection. The firmware of the USB PIC Programmer is also fully updatable as new devices are released and updates to the firmware can be easily downloaded via Microchip's official website.įind a list of supported PICs on CanaKit's product page.ICP01 offers unprecedented level of performance, reliability and scalability for PIC programmer solution with ICSP (In-Circuit Serial Programming) method.

Standalone windows programming software, fully supported by Microchip, is available for download. Higher pin count PICs can also be programmed, but through the ICSP connection header. The PIC Programmer offers In-circuit programming through a standard 6-pin ICSP connector as well as a built-in 20-pin ZIF socket for easy programming of any PIC of up to 20-pins right on the programmer. This PIC Programmer uses a USB port for power and connection to the computer, as opposed to the traditional serial port, eliminating the need for a separate power supply. The PIC Programmer is 100% compatible with Microchip's MPLAB IDE, and the PICkit 2 interface, and can program all popular PIC 5V microcontrollers including the PIC16F84, PIC16F628, PIC18F458 and PIC16F877. Description: This PIC programmer, from Cana Kit- Canada, is a professional, compact USB PIC Programmer offering a 20-pin ZIF (Zero Insertion Force) socket for easy PIC programming.
